Power requirements AC 220-240V, 50 Hz/60 Hz
Power consumption 9 W
Main unit weight 13.1 kg
Maximum dimensions
(W x H x D) 453 x 159 x 353 mm
Output RCA × 1
Turntable
Drive method Quartz lock servo type direct drive
Motor 3-phase brushless DC motor
Braking system Electronic brake
Rotation speed 33? rpm, 45 rpm
Rotation speed adjustment range ±8%, ±16%, ±50%
Wow and flutter 0.1% or less WRMS (JIS WTD)
S/N ratio 70 dB (DIN-B)
Turntable Aluminium die-casting diameter: 332 mm
Starting torque 4.5 kg/cm or more
Start time 0.3 seconds (at 33? rpm)
Tone arm
Arm type Universal type S-shape tone arm,
gimbal-supported type bearing structure, static balance type
Effective length 230 mm
Overhang 15 mm
Tracking error Within 3°
Arm height adjustment range 6 mm
Stylus pressure variable range 0 g to 4.0 g (1 scale 0.1 g)
Proper cartridge weight 3.5 g to 13 g (single cartridge)
- When shell weight is used: 3.5 g to 6.5 g
- When only balance weight is used: 6.0 g to 10 g
- When sub weight is used: 9.5 g to 13 g
Included accessories Turntable, turntable sheet, slip mat, slip sheet, dust cover, head shell, balance weight, sub weight, head shell, shell weight, adapter for EP record, power cord, audio cable, ground wire, operating instructions
